Key Features
- Increase vertical resolution by four times with a 14-bit analog-to-digital converter (ADC)
- See smaller signals with a 50 μVRMS noise floor
- Find signal glitches with a fast 1.3 M waveform/second update rate
- Capture longer time spans at full sample rate with 100 Mpts of deep memory
- Control your instruments for free with the PathWave BenchVue Basic app at www.keysight.com/find/BVBasic
Qualify
- Need more than 1 GHz of bandwidth? Sell 6000 X-Series or EXR Series.
- Need more information on probing solutions? See page 78, www.keysight.com/find/scope_probes or Oscilloscope Probes and Accessories: Technical Overview 5989-6162EN
Model Comparison
| HD302MSO | HD304MSO | |
| Analog channels | 2 | 4 |
| Bandwidth | 200/350/500 MHz/1 GHz | |
| Max sample rate | 3.2 GSa/s per channel | |
| Max memory rate | 100 Mpts per channel | |
| Resolution | 14 bit ADC, 16 bits high-res | |
| Waveform update rate | > 1,300,000 waveforms/sec | |
| Display | 10.1” Capacitive touch gesture-enabled display | |
Ordering Information
| Bandwidth Options | 200 MHz | 350 MHz | 500 MHz | 1 GHz |
| 2 Channel models (HD302MSO) | Standard | HD302MSO-350 | HD302MSO-500 | HD302MSO-01G |
| 4 Channel models (HD304MSO) | Standard | HD304MSO-350 | HD304MSO-500 | HD304MSO-01G |
New for 2024: InfiniiVision HD3
4x the resolution, half the noise
The InfiniiVision HD3 Series oscilloscope enables you to capture small signals more accurately than ever before with its low noise front-end and 14-bit analog-to-digital converter (ADC) oscilloscope, delivering 4x the signal resolution and half the injected noise of other general purpose oscilloscopes.
Combine this with fast waveform update rate, powerful new features such as Fault Hunter, deep memory, and hardware accelerated testing, and the HD3 Series is the perfect oscilloscope for your applications.
|
Portable Precision
|
|
Custom Technology
|
|
Versatile Functionality
|
