U1700 Handheld Capacitance and LCR Meters

What are you looking for?

Key Features
U1701B Capacitance Meter U1731C, U1732C, U1733C LCR Meter
  • 11,000 counts resolution with dual display
  • 20,000 counts resolution with dual display
  • Wide measurement range from 0.1 pF to 199.99 mF
  • Wide LCR ranges with three to five selectable test frequencies

  • Auto identification (Ai) automatically determines and displays component type and measurements

  • Detailed component analysis with DCR, ESR, Z, D, Q and q functions

Key Product Differentiator: Up to 100 kHz test frequency.

  U1701B U1731C U1732C U1733C
Counts 11,000 20,000
Capacitance 1000 pF to 199.99 mF 200 pF to 20 mF 20 pF to 20 mF
Inductance n/a 200 μH to 2000 H 20 μH to 2000 H
Resistance n/a 2 Ω to 200 MΩ
Test method/ frequency DC charge/discharge 100 Hz, 120 Hz, 1 kHz 100 Hz, 120 Hz, 1 kHz, 10 kHz 100 Hz, 120 Hz, 1 kHz, 10 kHz, 100 kHz
Backlit dual display ■



 ■
Tolerance mode 1%, 5%, 10%, 20%
Compare mode 25 sets of non-volatile high/low limit settings






Battery life 80 hours 16 hours
Additional features Min./max./avg. recording, data logging to PC

Included Accessories
  • U1781A alligator clip leads
  • Calibration certificate
  • Alkaline 9 V battery
Optional Accessories
U1780A AC power adapter and cord
U1174A Soft carrying case
U5481B IR-to-USB cable
U1176A LED probe clip light
U1781A Alligator clip leads
U1782B SMD tweezer
Data Sheet U1700 Series: 5990-3458EN
Data Sheet U1730C Series: 5990-7778EN
www.keysight.com/find/handheldlcr
