Key Features
- 10-bit ADC up to 8 GHz for additional resolution
- The most powerful and simple GUI
- Dedicated software/probes for Power Integrity and Signal Integrity
- Best selection of application specific options
- Most advanced jitter measurements
- Broad probe technologies to help you measure any signal anywhere
- Compliance test up to 8 GHz
Qualify
- Need more channels? Sell Infiniium EXR-Series.
- Need more information on probing solution? See page 76, www.keysight.com/find/scope_probes
- or Oscilloscope Probes and Accessories: Technical Overview 5989-6162EN
Model Comparison
|
|
|
DSO/MSO S054A |
DSO/MSO S104A |
DSO/MSO S204A |
DSO/MSO S254A |
DSO/MSO S404A |
DSO/MSO S604A |
DSO/MSO S804A |
|
Bandwidth (–3db) |
50 Ω |
500 MHz |
1 GHz |
2 GHz |
2.5 GHz |
4 GHz |
6 GHz* |
8 GHz* |
|
1 MΩ |
500 MHz |
|||||||
|
Channels |
DSO: 4 analog; MSO: 4 analog, 16 digital |
|||||||
|
Vertical resolution |
10 bits, up to 16 bits with high-resolution mode |
|||||||
|
Memory |
100 Mpt (standard) option up to 800 Mpts (2 channel) |
|||||||
|
Data offload |
USB 3.0, 1000BASE-T LAN |
|||||||
|
System |
Windows 10, 256 GB SSD, Quad Core i5, 8 GB RAM |
|||||||
*4 GHz when using 3 or 4 channels
Calibration & Warranty
| R-50C-011-3 | 3 Year Calibration Plan |
| R-50C-011-5 | 5 Year Calibration Plan |
| R-51B-001-5Z | 5 Year Warranty Plan |
Related Products
- Function generator
- Power supply
- Spectrum analyzer
Data Sheet: 5991-3904EN
