E5061B ENA Series Network Analyzer

What are you looking for?

Key Features

  • 2-port, 50 Ω or 75 Ω Vector network analyzer

  • Low frequency coverage down to 5 Hz

  • Built-in DC bias source

  • Impedance analysis capabilities

E5061B Highlights



Frequency

100 kHz to 1.5 GHz

(Option 115/215/117/217) 100 kHz to 3 GHz

(Option 135/235/137/237) 5 Hz to 500 MHz (Option 3L3) 5 Hz to 1.5 GHz (Option 3L4) 5 Hz to 3 GHz (Option 3L5)

System impedance

50 Ω (Option 115/215/135/235/3L3/3L4/3L5)

75 Ω (Option 117/217/137/237)

Test port options

- Economy transmission & reflection test set (Option 115/117/135/137)
– S-parameter test set (Option 215/217/235/237)
– S-parameter test set and gain-phase ports (Option 3L3/3L4/3L5)

Dynamic range

120 dB (spec)

Trace noise

0.005 dBrms (spec)

Stability

0.01 dB/°C

Key software capability

Time domain analysis, wireless power transfer analysis, impedance analysis



Qualify

  • Need to verify impedance parameters?

    E5061B-005 which works with the option 3L3/3L4/3L5.

  • Need higher frequency? Sell E5063A or P937xB Series.

Related Products

16092A

7-mm test fixture, 500 MHz, for MSD and leaded DUT

16196A

7-mm SMD test fixture, 3 GHz

16047E

4 terminal-pair test fixture, for leaded DUT

16034E/G/H

4 terminal-pair SMD test fixture



Software Options

005 Impedance analysis for Option 3L3, 3L4, 3L5

006 Wireless power transfer analysis for Option 3L3, 3L4, 3L5, 215, 235

010 Time domain analysis/fault location



Impedance Analysis

To ensure the performance and reliability of electronic equipment, it is crucial to evaluate impedance characteristics of various electronic components used in the circuits.



The E5061B Option 005 provides the impedance analysis capabilities for the E5061B ENA Vector Network Analyzer with Option 3L3/3L4/3L5. This software option enables the analyzer to measure impedance parameters of electronic components such as capacitors, inductors, and resonators.



The solution combines network analysis (NA) and impedance analysis (ZA) functions in a single instrument with comprehensive component and circuit characterization in a broad frequency range, 5 Hz to 3 GHz.

  • Plots impedance parameters with VNA firmware

  • Calibration / compensation capabilities for test fixtures

  • DC biased impedance measurements

  • Equivalent circuit analysis



Data Sheet: 5990-4392EN

www.keysight.com/find/e5061b
