These USB instruments offer a more compact size, with zero compromise in performance compared to benchtop instruments.
Note: Modular USB instruments listed on page 140 are not compatible with the Streamline Series instruments P937xA shown here, nor the P937xB and P938xB on page 128.
|
Key Features
-
Compact VNA with benchtop results
-
Wide choice of frequency ranges from 300 kHz up to 26.5 GHz
-
Frequency and software upgrades at any time
-
Common GUI within trusted Keysight VNAs
-
Support of Electronic Calibration (ECal) modules
Key Specifications
-
Measurement speed: 23 msec (201 points, full 2-port cal, 100 kHz IFBW)
-
Dynamic range: > 115 dB at 6.5 GHz (10 Hz IFBW)
-
Trace noise: < 0.003 dBrms (1 kHz IFBW)
-
Stability: 0.005 dB/°C up to 4.5 GHz
Qualify
-
Need time domain analysis? Sell option S97010B.
Ordering Configuration
2-port USB vector network analyzer
|
P9370A |
300 kHz to 4.5 GHz |
|
P9371A |
300 kHz to 6.5 GHz |
|
P9372A |
300 kHz to 9 GHz |
|
P9373A |
300 kHz to 14 GHz |
|
P9374A |
300 kHz to 20 GHz |
|
P9375A |
300 kHz to 26.5 GHz |
Software Applications
|
S97007B |
Automatic fixture removal |
|
S97010B |
Time domain analysis |
|
S97082B |
Scalar calibrated mixer and converter measurements |
|
S97551B |
N-port (multiport) calibrated measurements1 |
|
S97552B |
Multiport calibration assistant |
|
S97553B |
Multiport calibrated measurements with switch instruments2 |
1. The software enables a full featured four-port vector network analyzer, when two P937xA instruments are cascaded.
2. P9164A, P9165A, P9164B or P9165B full crossbar switch matrices are supported.
Accessories
|
Y1701A |
Multiple USB instruments configuration kit |
|
001 |
Interconnect cables for multiport configuration of P937xA |
|
101 |
Latch kit for connecting two 1-slot USB instruments |
|
Y1710A |
Transit case for Keysight USB modular products |
PC Requirements
|
Operating systems |
Windows 7 or Windows 10 (64 bit) |
|
Processor speed |
Intel i5 6th Generation or newer/Intel Xeon E3 v3 or newer |
|
Available memory |
4 GB minimum, 16 GB recommended |
|
Available disk space |
2 GB available drive space minimum |
|
Display resolution |
1024 X 768 minimum |
|
Connection |
USB 3.0 port directly connected to Intel chipset |
Data Sheet: 5992-2765EN
|
All Regions, All Partners can sell these products with these exceptions: EMEAI Premium Plus Distributors only, Not KSAP, Not GC Catalog. |
